High-Frequency On-Board Inverters
High-Frequency On-Board Inverters
Category: Car/On-board inverter
Wiices is a Chinese photovoltaic new energy manufacturer certified by the international certification facility SGS. Wiices also passed the ISO9001 quality management system certification and implemented ERP warehouse management.
Benefits&Protection
The shell is made of magnesium and aluminum total, which has good heatdissipation. The inverter works for a long time without getting hot and is impact-resistantFar superior to other materials.
The new generation ofintelligent chips quickly responds to security upgradesand provides multiple intelligent protection to ensure that the inverter is in useto full protection.
The high-density pure copper core refuses to be doped with aluminum wire,and the refined pure oxygen-free pure copper wire core has good conductivity,stable voltage, and no hot resistanceLower and more power-efficient.
Product Features
Product Parameters
| Model | S-300 | S-500 | S-1000 | S-1500 | S-2000 |
| Rated output power | 150W | 250W | 500W | 750W | 900W |
| Output voltage | 220V | ||||
| Output frequency | 50-60HZ | ||||
| DC input voltage | 12V | ||||
| Current rating | 75A | ||||
| Peak loadvalue | 3:1 | ||||
| Output voltage regulation | ±10% | ||||
| Battery type | Lead-acid,colloidal,colloidaldeep circulation,lithium battery | ||||
| Output protection | Under inverter overload,reverseconnection,short circuit,overtemperature,overvoltage,undervoltage protection | ||||
| LEDs indicate status | Green:Protect;Red:Workinstructions | ||||
| Storage temperature | 15℃~45℃ | ||||
| Operating temperature | 0℃~60℃ | ||||
| Relative temperature | -10℃~90℃No condensation | ||||
| Noises | <55dB | ||||
| Machine Size(L*W*H)(mm) | 155*150*68 | 180*150*68 | 220*150*68 | 240*170*70 | 270*170*70 |
| FCL packing size(mm) | 590*320*370 | 590*370*370 | 450*420*320 | 470*430*370 | 540*430*370 |
| Net weight(KG) | 0.55 | 0.6 | 0.85 | 0.95 | 1 |
Product Accessories:
