Rack/cabinet energy storage lithium battery

Category: Cabinet batteries

Wiices is a Chinese photovoltaic new energy manufacturer certified by the international certification facility SGS. Wiices also passed the ISO9001 quality management system certification and implemented ERP warehouse management.

Consult Contacts

Key words：Solar Power SystemVoltage Regulators

PRODUCT DETAILS

Product Overview

The cabinet series adopts high-quality lithium iron phosphate batteries, equippedwith intelligent BMs battery management system, cycleLong life,high safety performance, beautiful appearance, free combination, easy installation.LCD Visualization ofbattery operation data. Compatible with most solar inverters, for photovoltaic off-gridhouseholds, businessesand other electrical applications to provide efficient energy.

Product Parameters

Model	C4850		C4810		C48200
Product Specifications	48V50AH	51.2V50AH	48V100AH	51.2V100AH	48V200AH	51.2V200AH
Combinations	15S1P	16S1P	15S1P	16S1P	15S1P	16S1P
Battery pack capacity	2.4KWh	2.56KWh	4.8KWh	5.12KWh	9.6KWh	10.24KWh
Standard discharge current	50A	50A	50A	50A	50A	50A
Maximum discharge current	100A	100A	100A	100A	100A	100A
Operating voltage range	40.5-DC54V	43.2-DC57.6V	40.5-DC54V	43.2-DC57.6V	40.5-DC54V	43.2-DC57.6V
Standard voltage	DC48V	DC51.2V	DC48V	DC51.2V	DC48V	DC51.2V
Maximum charging current	50A	50A	50A	50A	100A	100A
Maximum charging voltage	54V	57.6V	54V	57.6V	54V	57.6V
Recommended depth of discharge	The numberof cycles is 3000~6000 times@D0D80%/25℃/0.5℃
Operating humidity/ operatingtemperature	65±20%RH/-10~+50℃
Working altitude	≤2500 meters
Cooling method	Naturalcooling
Installation	Cabinet/rack mounting
Degree of protection	IP20
Maximum number of parallels	15PCS
Methods of Communication	Default:RS485/RS232/CAN optional WIFI/4G/Bluetooth
Product Certification/Warranty	CE ROHS FCC UN38.3MSDS/5-10years
Product dimensions	25/30	37/42	41/49	45/55	101/111	115
Packing Size(LWH)(mm)	44049588/550500130		440495178/555500235		440590178/480650220
